| | 滤膜类型：反渗透膜 | | 品牌：东丽 | | 适用对象：药液 | |
| | 用途：药液过滤 | | 规格：8040 | | 厚度：1.2 | |
| | 适用范围：水泵 | | 过滤方式：内压式 | | 性能：耐酸;耐碱 | |
| | 操作压力：1.6 Mpa | | 工作温度：1-45 ℃ | | 过滤精度：0.01 | |
| | 截留分子量：10 万 | | 孔径：0.01 μm | | 通量：1000 L/H | |
| | 纵向强度：1.6 Mpa | | 型号：SUL-G20ST | | 膜面积：400M2 | |
| | 货期：现货 | | 货量：1000 | | 产地：日本 | |
| | 产水量：500L/H | | | | | |
现货供应日本东丽卫生级热水消毒膜SUL-G20ST
在线咨询QQ:--- 安小姐：
日本东丽卫生级热水消毒膜SUL-G20ST
Salt Rejection:99.5%;Product Flow Rate:30m3/day (7900gpd)
1. Test Conditions日本东丽卫生级热水消毒膜SUL-G20ST
Feed Water Pressure 0.75 MPa (110 psi)
Feed Water Temperature 25 °C (77 °F)
Feed Water Concentration 500 mg/ as NaCl
Brine Flow Rate 80 /min. (5.3 gpm)
Feed Water pH 6.5
2. 99.0 % minimum*日本东丽卫生级热水消毒膜SUL-G20ST
3. 24 m3/day (1100 gpd) minimum* *For any single element
日本东丽卫生级热水消毒膜SUL-G20ST
Design Conditions
Feed Water Pressure ＜1.0 MPa (150 psi)
Feed Water Temperature ＜35 °C (95 °F)
Feed Water Turbidity ( SDI ) ＜4
Feed Water pH Range, Continuous Operation 3-9
Feed Water pH Range, Chemical Cleaning 2-11
Feed Flow Rate per Vessel ＜200/min. (52 gpm)
Brine Flow Rate per Vessel ＞ 40/min. (11 gpm)
Brine/Permeate Flow Ratio＞6日本东丽卫生级热水消毒膜SUL-G20ST
Pressure Drop ( per Element ) ＜0.10 MPa (14 psi)
Pressure Drop ( per Vessel ) ＜0.20 MPa (29 psi)
本公司还供应上述产品的同类产品：SUL-G10TS,SUL-G10,SUL-G20F
日本东丽卫生级热水消毒膜SUL-G20ST
